    Stability Laboratory Humidity Chamber , High Low Temp Humidity Chamber

    Ask Lasest Price
    Model Number : TZ-HW1000
    Certification : CE Complied
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, , MoneyGram
    Supply Ability : 500 sets/ month
    Delivery Time : 5-7 working days
    • Product Details
    • Company Profile

    Stability Laboratory Humidity Chamber , High Low Temp Humidity Chamber

    Stability Laboratory Humidity Chamber , High Low Temp Humidity Chamber


    Temp Humidity Chamber Feature


    1. High performance and quiet operation

    2. Space-saving designed for flush installation to wall

    3. Full thermal break around doorframe

    4. One 50mm diameter cable port o left, with flexible silicone plug

    5. Accurate wet/dry-bulb humidity measurement system for easy maintain


    Temp Humidity Chamber ADVANTAGES

    1. The product has excellent performance and durability with reasonable price,can be customized according to the special needs of customers.
    2. Independent product design, production, production in strict accordance with the process requirements, beautiful appearance.

    3. Famous brands are adopted for key components to guarantee the performance and quality.

    4. We company established a sound quality assurance system and complete after-sales service guarantee system.

    Temp Humidity Chamber INTRODUCTION

    This product is suitable for testing various products or materials, household electrical appliances, instruments, components and other electrical, electronic, automobile, motorcycle products under high temperature, low temperature, humidity environment conditions, for various scientific research institutions and factories and mines center test room to do reliability test.


    Temp Humidity Chamber TECHNICAL PARAMETERS


    ModelTZ-HW1000 Temp Humidity Chamber
    Internal Volume(L)1000L
    DimensionsStudio Size(mm)1000*1000*1000
    Machine Size(mm)1500*1500*1900
    StructureCombined structure (If the door is not wide enough, small size is available, width reduced by 250 ~ 300mm)
    Weight (Kg)About 800
    PerformanceTest Environment ConditionsEnvironment temperature+25ºC,Relative humidity≤85%,No sample in test chamber.
    Corresponding Standard

    GB/T 5170.2-1996 "Method for verification of basic parameters of

    environmental test equipment for electric and electronic products"

    Test MethodCompletely stationary test mode for the object to be measured.
    This method is the first choice for testing, research and semiconductor
    screening of electronic components.
    ParametersControl MethodsBalanced temperature and humidity control mode(BTHC) PID Intelligent Adjustment
    Temperature Range-40ºC~+150ºC -70ºC~+150ºC
    Humidity Range20%~98%R.H (0%~100% R.H can be customized)
    Heating Rate1-2ºC/min (Linear Adjustment 3-5℃/min can be Customized)
    Cooling Rate0.7ºC-1ºC/min (Linear Adjustment 3-5℃/min can be Customized)
    UniformityTemperature: ±1.5ºC Humidity: ±2.5%R.H
    FluctuationTemperature: ±0.5ºC Humidity : ±2%R.H

    Temperature

    Calibration

    Point

    +23 °C and +80 °C

    Details
