    Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber

    Ask Lasest Price
    Model Number : TZ-HW408
    Certification : CE Complied
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, , MoneyGram
    Supply Ability : 500 sets/ month
    Delivery Time : 5-7 working days
    • Product Details
    • Company Profile

    Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber

    Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber


    Humidity And Temperature Controlled Chamber Introduction


    Constant Temperature Humidity Chambers can simulate the different indicators of constant temperature and humidity climate quickly and accurately for testing products which need to check their performance of temperature testing (-40℃~+150℃), humidity testing (20~98%R.H.),both of temerature and humidity testing at the same time.chamber power can be customized.

    Constant Temperature Humidity Chamber which also call environment test chamber is designed for detecting the material under a variety of environmental test equipment and performance of a variety of materials holding test, cooling-off test, heating-up test, moistening test and drying test... Suitable for electronic, electrical, communications, instrumentation, vehicles, plastic products, metals, food, chemicals, building materials, medical, aerospace and other products quality testing purposes,EN 14511.


    Humidity And Temperature Controlled Chamber Application:


    This Chamber can simulate different environment condition. It's appropriate for testing material performance, such as resist heat, resist dry,resist humidity and resist cold. That can define performance of material.


    The temperature and humidity test chamber can accurately simulate the complex natural environment of low temperature, high temperature, high humidity, low temperature and low humidity, which is suitable for the product detection of plastics, electronics, food, clothing, vehicles, metals, chemicals, building materials and other industries.


    Humidity And Temperature Controlled Chamber Parameters


    ModelTZ-HW80TZ-HW150TZ-HW225TZ-HW408TZ-HW1000
    Internal Volume(Liters)801502254081000
    DimensionStudio size(mm)400*400*500500*500*600500*600*750600*800*8501000*1000*1000
    Machine size(mm)900*902*13501005*995*14651050*1100*17001100*1350*17501500*1500*1950
    StructureCombined structure(If the door is not wide enough, small size is available , width can be reduced by 250~300mm)
    Weight(kg)Around 280Around 280Around 300Around 500Around 800
    PerformanceTest environment conditionsTest environment temperature +25°C, relative humidity≤85%, No sample in test chamber
    Corresponding standardGB/T 5170.2-1996 “Method for verification of basic parameters of environmental test equipment for electric and electronic products”
    Test Method

    Completely stationary test mode for the object to be measured

    This method is the first choice for testing, research and semiconductor screening of electronic components

    ParametersControl methodBalanced temperature and humidity control mode(BTHC) PID Intelligent Adjustment
    Temperature range-40°C~+150°C
    Humidity range20%~98%R.H
    Heating rate1-1.5°C/min
    Cooling rate0.7-1°C/min
    UniformityTemperature: ±1.5°C Humidity: ±2.5%R.H
    FluctuationTemperature: ±0.5°C Humidity: ±2.0%R.H
    Temperature Calibration point+23°C and +80°C

    Package details


    1. External wooden case with tray
    2. The total volume is about 3-6 square
    3. Suitable for export, loading and unloading
    Packaging details are as follows:
